Materials:

Satin-finish stainless steel. Equipped with tumbler lock; vandal-resistant. Dispenses single-fold toilet tissue. 5-1/16" (129mm) x 9-1/16" (230mm) x 4-5/16" (109mm).

Shell and Flange . 18-8 S, type-304, 22-gauge (0.8mm) stainless steel. Drawn and beveled, one-piece, seamless construction with four countersunk mounting holes.

Support Posts (4) . Heavy-duty cast zamac with chrome-plated finish.

Hoods (2) . 18-8 S, type-304, 18-gauge (1.2mm) stainless steel. Hoods hinged to shell.

Mounting Bracket . Plated-steel mounting clamp attaches to back of unit with two sheet-metal screws for installation in stud walls or countertop aprons.

Spindles (2) . Chrome-plated plastic. Equipped with heavy-duty internal springs.
Designer's Note: Theft-resistant toilet tissue spindles, which are removable only with special key provided, are available as an optional accessory. To specify, add suffix .60 to model number. Example: B-699.60.

Installation:
Provide framed rough opening 11-3/4" wide x 5-1/4" high (300 x 135mm). Minimum recessed depth required from finish face of wall or apron is 3-3/8" (86mm). For installation in stud walls or countertop aprons without backing, loosely attach mounting clamp to back of unit with mounting screws. Insert into rough opening. Adjust mounting clamp so it grips surface inside rough opening. Secure in place by tightening four mounting screws. For installation in stud walls or countertop aprons with backing, discard mounting clamp furnished with unit. Insert unit only into rough opening and secure with sheet-metal screws furnished. Backing must comply with local building codes.

Specification:
Recessed dual-roll toilet tissue dispenser shall be type-304 stainless steel with __________ (insert one: bright polished or satin) finish. Shell and flange shall be drawn and beveled, one-piece, seamless construction. Unit shall be equipped with 18.gauge (1.2mm) hoods hinged to shell and furnished with plated-steel mounting clamp for installation in stud walls or countertop aprons. *Spindles shall be chrome-plated plastic with heavy-duty internal springs. Manufacturer's service and parts manual shall be provided to the building owner/manager upon request.
