Products
Electronic Hand Washing Faucet ETF-80-LT
Brands:SLOAN VALVE
Model:
Description:Electronic Hand Washing Faucet ETF-80-LT
Description
Sensor Activated Electronic Hand Washing Faucet for tempered or hot/cold water operation.
Flow Rate
£0.5 gpm/1.9 Lpm Vandal Resistant Spray Head
(See Accessories for other Spray Head options)
Specifications
ADA Compliant, Sensor Activated, 24 VAC, Chrome Plated Brass, Hand Washing Faucet with the
following features:
• Splash-proof Circuit Control Module
• Sensor Range Adjustment Screw
• Troubleshooting LED Indicator Lights
• User Friendly Variable Time Out Settings
• Filtered Solenoid Valve with serviceable Strainer Filter
• Bak-Chek® Tee for Hot/Cold Supply
• Trim Plate with Anti-Rotation Pin (specify 4” or 8”)
• 120 VAC/24 VAC Transformer (specify Plug-in or Box Mount)
• Vandal Resistant Spray Head with Pressure Compensating Flow Control
• Metal Jacketed Wire Protection for Sensor and Solenoid Leads
• Modular Quick-Release Sensor and Solenoid Connections
Variations
(Add suffix to Model Number for inclusion with Faucet)
• Trim Plate (must be specified)
£ -4 Trim Plate for 4” Center-Set Sink
£ -8 Trim Plate for 8” Center-Set Sink
• Transformer Type (must be specified)
£ P Plug-in Transformer (furnished with ETF-233)
£ B Box Mount (furnished with EL-248-40)
£ LT Less Transformer
(specify Transformer separately - See Accessories)
• Temperature Mixing Valves (optional)
£ ADM Above Deck Mechanical Mixing Valve
£ BDM Below Deck Mechanical Mixing Valve
£ BDT Below Deck Thermostatic Mixing Valve
Bak-Chek® Tee not required or provided when a Temperature Mixing Valve is included with the
faucet.
Consult Factory for Finish Variations
Accessories (Specify separately)
• Transformers
£ ETF-233 120 VAC/24 VAC, 50/60 Hz (35 VA) - Plug-in
(will operate up to 2 faucets)
£ EL-248-40 120 VAC/24 VAC, 50/60 HZ (40 VA) - Box Mount
(will operate up to 2 faucets)
£ EL-154 120 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
£ EL-208 120 VAC/24 VAC, 50/60 HZ (100 VA) - Foot Mount
(will operate up to 6 faucets)
£ EL-342 240 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
• Vandal Resistant Spray Heads
£ ETF-1028-A 1.5 gpm/5.7 Lpm Laminar Flow Spray Head
(recommended for medical applications)
• Grid Strainer
£ ETF-460-A Chrome Plated Brass Grid Strainer w/1¼” Outlet Tube
See OPTIMA Accessories Section of the Sloan Catalog for a complete listing of OPTIMA Faucet
Sensor Activated Electronic Hand Washing Faucet for tempered or hot/cold water operation.
Flow Rate
£0.5 gpm/1.9 Lpm Vandal Resistant Spray Head
(See Accessories for other Spray Head options)
Specifications
ADA Compliant, Sensor Activated, 24 VAC, Chrome Plated Brass, Hand Washing Faucet with the
following features:
• Splash-proof Circuit Control Module
• Sensor Range Adjustment Screw
• Troubleshooting LED Indicator Lights
• User Friendly Variable Time Out Settings
• Filtered Solenoid Valve with serviceable Strainer Filter
• Bak-Chek® Tee for Hot/Cold Supply
• Trim Plate with Anti-Rotation Pin (specify 4” or 8”)
• 120 VAC/24 VAC Transformer (specify Plug-in or Box Mount)
• Vandal Resistant Spray Head with Pressure Compensating Flow Control
• Metal Jacketed Wire Protection for Sensor and Solenoid Leads
• Modular Quick-Release Sensor and Solenoid Connections
Variations
(Add suffix to Model Number for inclusion with Faucet)
• Trim Plate (must be specified)
£ -4 Trim Plate for 4” Center-Set Sink
£ -8 Trim Plate for 8” Center-Set Sink
• Transformer Type (must be specified)
£ P Plug-in Transformer (furnished with ETF-233)
£ B Box Mount (furnished with EL-248-40)
£ LT Less Transformer
(specify Transformer separately - See Accessories)
• Temperature Mixing Valves (optional)
£ ADM Above Deck Mechanical Mixing Valve
£ BDM Below Deck Mechanical Mixing Valve
£ BDT Below Deck Thermostatic Mixing Valve
Bak-Chek® Tee not required or provided when a Temperature Mixing Valve is included with the
faucet.
Consult Factory for Finish Variations
Accessories (Specify separately)
• Transformers
£ ETF-233 120 VAC/24 VAC, 50/60 Hz (35 VA) - Plug-in
(will operate up to 2 faucets)
£ EL-248-40 120 VAC/24 VAC, 50/60 HZ (40 VA) - Box Mount
(will operate up to 2 faucets)
£ EL-154 120 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
£ EL-208 120 VAC/24 VAC, 50/60 HZ (100 VA) - Foot Mount
(will operate up to 6 faucets)
£ EL-342 240 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
• Vandal Resistant Spray Heads
£ ETF-1028-A 1.5 gpm/5.7 Lpm Laminar Flow Spray Head
(recommended for medical applications)
• Grid Strainer
£ ETF-460-A Chrome Plated Brass Grid Strainer w/1¼” Outlet Tube
See OPTIMA Accessories Section of the Sloan Catalog for a complete listing of OPTIMA Faucet
Accessories and Variations.
