Products
BASYS® Any Application. Any Environment.®
Brands:SLOAN VALVE
Model:
Description:BASYS® Any Application. Any Environment.®
Faucet Specifications
Solar powered, sensor-activated, electronic, chrome plated die cast
body, handwashing faucet with the following features:
• All serviceable components in spout
• One tool service
• All wetted components to be stainless steel, engineered
thermoplastic, EPDM and copper or copper alloy
• Solenoid housed in removable carrier that includes supply strainer,
serviceable from above deck
• Integral water supply shut off
• Vandal resistant spray insert, key housed inside faucet body
• All electronics sealed to IP-67
• Gold plated electrical contacts
• In spout individual diagnostic indicators for battery life,
solenoid condition, and power-up mode
• Bi-stable magnetic solenoid
• Faucet can be configured to add solar and LCD display
• One (1) CR-P2 Lithium battery (acts as back-up)
• Double infrared sensors
• Includes all mounting hardware
• Selectable Sloan programmable line purge mode eliminates
stagnant water
• Operates from 1 to 125 psi
• Adjustable run time from 0-3600 seconds (factory set at
10 second maximum run time upon continuous detection)
• Optional Wall Flange included
• Time Out Setting-30 seconds maximum time faucet will run upon
continuous detection
Electrical Specifications
• Control Circuit – 6.75 VDC
• Sensor Range – Factory Setting: 4”- 5” (102-127 mm) Nominal
Range Adjustment: 1”- 6” (25-150 mm) Nominal
• Battery Life – 5-years under worst case conditions of 8,000 cycles
per month and high water pressure without power harvesting.
Power harvesting should extend service life of batteries.
• Power Supplies – 6 VDC Solar Energy Module with 6 VDC Lithium
Battery Pack
Warranty
3 Year Limited
Meets or Exceeds
ASME A112.18.1/CSA B125.1, NSF 372, ANSI/UL 1951,
ICC/ANSI 117.1
Certifications
IAPMO/cUPC, Commonwealth of Massachusetts
Codes Compliance
UPC, IPC, NPC Canada, California Green Building Code (CALGreen),
City of Los Angeles Water Efficiency Ordinance
CALGreen
This BASYS faucet with a 10-second cycle uses 0.083 gallons of water
at 0.5 gallons per minute (exceeds minimum CALGreen requirements) or
0.25 gallons of water at 1.5 gallons per minute, depending upon desired
flow rate. Additionally, this BASYS faucet is Sloan reprogrammable to
use 0.175 gallons of water at 1.5 gallons per minute with a 7-second
cycle (exceeds minimum CALGreen requirements).
Legislative Compliance
Federal Reduction of Lead in Drinking Water Act Law 111-380 (contains
no more than 0.25% weighted average lead content), Section 116875 of
the California Health & Safety Code, and Vermont Lead Reduction Law
(Vermont Act 193).
ADA Compliant
BASYS Spec Language
Sloan BASYS model no. EFX-875.____._____ double infrared
sensor-activated electronic handwashing faucet with battery back-up
and line purge mode for pre-tempered water supplies. Product to have
double infrared sensors with automatic setting feature. Solenoid valve
housed in removable carrier that closes water supply upon removal
eliminating need to access control stops. Solenoid carrier includes
strainer for easy above-deck service. Optional thermostatic mixer
Solar powered, sensor-activated, electronic, chrome plated die cast
body, handwashing faucet with the following features:
• All serviceable components in spout
• One tool service
• All wetted components to be stainless steel, engineered
thermoplastic, EPDM and copper or copper alloy
• Solenoid housed in removable carrier that includes supply strainer,
serviceable from above deck
• Integral water supply shut off
• Vandal resistant spray insert, key housed inside faucet body
• All electronics sealed to IP-67
• Gold plated electrical contacts
• In spout individual diagnostic indicators for battery life,
solenoid condition, and power-up mode
• Bi-stable magnetic solenoid
• Faucet can be configured to add solar and LCD display
• One (1) CR-P2 Lithium battery (acts as back-up)
• Double infrared sensors
• Includes all mounting hardware
• Selectable Sloan programmable line purge mode eliminates
stagnant water
• Operates from 1 to 125 psi
• Adjustable run time from 0-3600 seconds (factory set at
10 second maximum run time upon continuous detection)
• Optional Wall Flange included
• Time Out Setting-30 seconds maximum time faucet will run upon
continuous detection
Electrical Specifications
• Control Circuit – 6.75 VDC
• Sensor Range – Factory Setting: 4”- 5” (102-127 mm) Nominal
Range Adjustment: 1”- 6” (25-150 mm) Nominal
• Battery Life – 5-years under worst case conditions of 8,000 cycles
per month and high water pressure without power harvesting.
Power harvesting should extend service life of batteries.
• Power Supplies – 6 VDC Solar Energy Module with 6 VDC Lithium
Battery Pack
Warranty
3 Year Limited
Meets or Exceeds
ASME A112.18.1/CSA B125.1, NSF 372, ANSI/UL 1951,
ICC/ANSI 117.1
Certifications
IAPMO/cUPC, Commonwealth of Massachusetts
Codes Compliance
UPC, IPC, NPC Canada, California Green Building Code (CALGreen),
City of Los Angeles Water Efficiency Ordinance
CALGreen
This BASYS faucet with a 10-second cycle uses 0.083 gallons of water
at 0.5 gallons per minute (exceeds minimum CALGreen requirements) or
0.25 gallons of water at 1.5 gallons per minute, depending upon desired
flow rate. Additionally, this BASYS faucet is Sloan reprogrammable to
use 0.175 gallons of water at 1.5 gallons per minute with a 7-second
cycle (exceeds minimum CALGreen requirements).
Legislative Compliance
Federal Reduction of Lead in Drinking Water Act Law 111-380 (contains
no more than 0.25% weighted average lead content), Section 116875 of
the California Health & Safety Code, and Vermont Lead Reduction Law
(Vermont Act 193).
ADA Compliant
BASYS Spec Language
Sloan BASYS model no. EFX-875.____._____ double infrared
sensor-activated electronic handwashing faucet with battery back-up
and line purge mode for pre-tempered water supplies. Product to have
double infrared sensors with automatic setting feature. Solenoid valve
housed in removable carrier that closes water supply upon removal
eliminating need to access control stops. Solenoid carrier includes
strainer for easy above-deck service. Optional thermostatic mixer
complies with ASSE 1070 requirements.
