Brands:Chicago Faucets
Model:
Description:Chicago Faucets 3-Handle Side Sprayer Kitchen Faucet in Chrome 509-GCLABCP
MECHANICAL FAUCETS
509-GCLABCP
Pre-Rinse Fittings
Product Type
___________________________________________________
Wall Mounted 8" Body, Adjustable Arms 7 1/4" - 8 3/4"
Pre-Rinse Fitting with 613-A Adapta-Faucet
Features & Specifications
___________________________________________________
• 8" Body, Adjustable Arms 7 1/4" - 8 3/4"
• 1.0 GPM @ 60 PSI Spray
• 2-3/8" Lever Handle
• Quaturn Compression Operating Cartridge
• 3/8" Offset Inlet Supply Arm with Integral Check with 1/2"
NPT Female Thread Inlet
• Secondary Control Valve
• 9-1/2" L Type Swing Spout
• Full Flow Outlet
• 2-3/8" Lever Handle
• Quaturn Compression Operating Cartridge
• 2 5/16" Diameter Slip Flange
• 60" Flexible Stainless Steel Hose
• Compatible with Fisher and T&S Hoses
• ECAST® design provides durable brass construction with
total lead content equal to or less than 0.25% by weighted
average
• CFNow! Item Ships in 5 Days
Performance Specification ___________________________________________________
• Rated Operating Pressure: 20-125 PSI
• Rated Operating Temperature: 40-140oF
Warranty
___________________________________________________
• Lifetime Limited Faucet Warranty
• 5-Year Limited Cartridge Warranty
• 1-Year Limited Finish Warranty
Codes & Standards
___________________________________________________
• ASME A112.18.1/CSA B125.1
• Certified to NSF/ANSI 61, Section 9 by CSA
• California Health and Safety Code 116875 (AB1953-2006)
• Vermont Bill S.152
• NSF/ANSI 372 Low Lead Content
509-GCLABCP
Pre-Rinse Fittings
Architect/Engineer Specification ________________________________________________________________________________________________________
Chicago Faucets No. 509-GCLABCP, Wall Mounted 8" Body, Adjustable Arms 7 1/4" - 8 3/4" Pre-Rinse Fitting with 613-A Adapta-Faucet,
Chrome Plated solid brass construction. 1.0 GPM @ 60 PSI Water Conserving Pre-Rinse Valve Spray. 2-3/8" Metal Lever handle(s) with
Sixteen Point Tapered Broach and Secured Blue and Red Buttons. Quaturn™ rebuildable compression cartridge, opens and closes 90°, closes
with water pressure, features square tapered stem. 3/8" Offset Inlet Supply Arm with Integral Check with 1/2" NPT Female Thread Inlet. 2 5/16"
Diameter Slip Flange. 60" Flexible Stainless Steel Hose. Compatible with Fisher and T&S Hoses. ECAST® construction with less than 0.25%
lead content by weighted average. Secondary Control Valve: 9-1/2" Center to Center L Type Swing Spout. Full Flow Quixtop with Single Screen
Design Outlet. 2-3/8" Metal Lever handle(s) with Sixteen Point Tapered Broach and Secured White Button. Quaturn™ rebuildable compression
cartridge, opens and closes 90°, closes with water pressure, features square tapered stem. This product is tested and certified to industry
standards: ASME A112.18.1/CSA B125.1, Certified to NSF/ANSI 61, Section 9 by CSA, California Health and Safety Code 116875
(AB1953-2006), Vermont Bill S.152, and NSF/ANSI 372 Low Lead Content.
