Sensor Activated Electronic Pedestal Faucet ETF-800
Brands:SLOAN VALVE
Model:
Description:Sensor Activated Electronic Pedestal Faucet ETF-800
Description
Wall Mounted, Sensor Activated Electronic Hand Washing Faucet for tempered
or hot/cold water operation.
Flow Rate
£1.5 gpm/5.7 Lpm Laminar Flow Spray Head
Specifications
ADA Compliant, Sensor Activated, 24 VAC, Chrome Plated Brass, Hand
Washing Faucet with the following features:
• Splash-proof Circuit Control Module
• Sensor Range Adjustment Screw
• Troubleshooting LED Indicator Lights
• User friendly Variable Time Out Settings
• Filtered Solenoid Valve with serviceable “Y” Strainer Filter
• Bak-Chek® Tee for Hot/Cold Supply
• 120 VAC/24 VAC Transformer (specify Plug-in or Box Mount)
• Spray Head with Pressure Compensating Flow Control
• Metal Jacketed Wire Protection for Solenoid Leads
• Modular Quick-release Sensor and Solenoid Connections
• Optional 0.5 gpm/1.9 Lpm Max. Spray Head included
Variations
(Add suffix to Model Number for inclusion with Faucet)
• Transformer Type (must be specified)
£ P Plug-in Transformer (furnished with ETF-233)
£ B Box Mount (furnished with EL-248-40)
£ LT Less Transformer
(specify Transformer separately - See Accessories)
Consult Factory for Finish Variations
Accessories (Specify separately)
• Transformers
£ ETF-233 120 VAC/24 VAC, 50/60 Hz (35 VA) - Plug-in
(will operate up to 2 faucets)
£ EL-248-40 120 VAC/24 VAC, 50/60 Hz (40 VA) - Box Mount
(will operate up to 2 faucets)
£ EL-154 120 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
• Grid Strainer
Wall Mounted, Sensor Activated Electronic Hand Washing Faucet for tempered
or hot/cold water operation.
Flow Rate
£1.5 gpm/5.7 Lpm Laminar Flow Spray Head
Specifications
ADA Compliant, Sensor Activated, 24 VAC, Chrome Plated Brass, Hand
Washing Faucet with the following features:
• Splash-proof Circuit Control Module
• Sensor Range Adjustment Screw
• Troubleshooting LED Indicator Lights
• User friendly Variable Time Out Settings
• Filtered Solenoid Valve with serviceable “Y” Strainer Filter
• Bak-Chek® Tee for Hot/Cold Supply
• 120 VAC/24 VAC Transformer (specify Plug-in or Box Mount)
• Spray Head with Pressure Compensating Flow Control
• Metal Jacketed Wire Protection for Solenoid Leads
• Modular Quick-release Sensor and Solenoid Connections
• Optional 0.5 gpm/1.9 Lpm Max. Spray Head included
Variations
(Add suffix to Model Number for inclusion with Faucet)
• Transformer Type (must be specified)
£ P Plug-in Transformer (furnished with ETF-233)
£ B Box Mount (furnished with EL-248-40)
£ LT Less Transformer
(specify Transformer separately - See Accessories)
Consult Factory for Finish Variations
Accessories (Specify separately)
• Transformers
£ ETF-233 120 VAC/24 VAC, 50/60 Hz (35 VA) - Plug-in
(will operate up to 2 faucets)
£ EL-248-40 120 VAC/24 VAC, 50/60 Hz (40 VA) - Box Mount
(will operate up to 2 faucets)
£ EL-154 120 VAC/24 VAC, 50/60 Hz (50 VA) - Box Mount
(will operate up to 3 faucets)
• Grid Strainer
£ ETF-460-A Chrome Plated Brass Grid Strainer w/1¼” Outlet Tube
